White kraft paper tand up zip lock bags with logo print with clear window Size:12*23+8cm. Material:MOPP/white kraft paper/PE Thickness:140 micron/side. We can do custom with your own material,size,and design,pls provide us your bag information,our email:sales7@jurenbz.com. Free samples...

  • Product Introduction



The Basics


Bag Type: White Kraft Paper Stand-up Pouch with Zipper (includes a transparent window)
Reference size: 12 × 23 + 8 cm (W × H + bottom gusset)
Structure: MOPP / white kraft paper / PE
Thickness: 140 μm/side
MOQ: from 5,000 pcs, varies by order type
Printing: Rotogravure printing, customized with client logo
Features/Accessories: Zipper, transparent window
Sample: Factory-direct pricing; free samples available-you only need to cover the shipping costs.
Full Specs

Specifications: made from white kraft paper, gradations, and a transparent front window, resealable zip lock, and logo printed using pressure printing.



Available sizes: width in the range of 80 - 300 mm, height from 100 to 450 mm, and bottom gusset varies from 0 to 100 mm. For pouch size lesser than 80 mm in height, flat pouch would be more suitable.



Available thicknesses: 100 to 180 μm. In case of thickness being lesser than 120 μm, the seal might not be strong, and so we don't recommend it for powdered products. Thickness in the range of 120 - 130 μm could be ideally chosen based on the filler used and sealing temperature. For thickness above 160 μm, the pouch may become difficult to use and this could require a change in the type of zip.



Other structures: PET/VMPET/PE for oxygen and moisture sensitivity. PET/AL/PE for coffee and anything that needs light or aroma protection. Matte BOPP/VMPET/PE if you want matte plus a barrier.



Printing: gravure, 1–10 colors, good for medium and large runs. Digital has no plate fee and works well at the 5,000 pcs level for a first order. Local UV adds a plate.



Artwork: AI, CDR or PDF, vector, text outlined. Bitmap 300 dpi or better. CMYK, Pantone numbers for spot colors.



Quality targets: heat-seal ≥3.5 N/15mm at 140 μm/side, zipper reclose ≥20 cycles, lamination strength ≥2.5 N/15mm, batch color ΔE ≤3.



Traceability: samples kept 6 months, COA and food-contact statements available.

1
2





Picking Size and Add-Ons

Begin with the fill weight and the available shelf space. Side gusset and opening of the bag are customizable. We confirm from your artwork the shape and position of the window and define the safety zone, ensuring that the edge does not touch the sealing and the zipper at any point.

One thing on fine powder: leave a clean strip above the fill line. Otherwise powder works its way into the zipper track and the reclose weakens faster than the lab number suggests. We can shift the window and zipper landing area together to reduce that.

Hang hole, tear notch and one-way valve are available. MOQ and lead time for each are in the order guide below.

3





Picking the Film

The reference MOPP/kraft/PE works for most general food powders. For oxygen or moisture-sensitive stuff, go PET/VMPET/PE. Coffee or aroma-sensitive products, PET/AL/PE. Matte look plus barrier, matte BOPP/VMPET/PE.

Whether 140 μm is sufficient is highly dependent on the fill weight, height of the drop and humidity of the filling room. Good results in dry conditions do not guarantee the same performance in humid surroundings, especially in case of powdery materials prone to clumping. When working with heavier fills we would normally prefer to test the thickness rather than make assumptions based on the thickness of the film.

If you have OTR or WVTR targets, send them with the application. See our material guide for side-by-side comparisons.



4





Printing Notes

Kraft paper suits natural matte artwork. If the design has a big smooth gradient on the kraft area, look at glossy composite film before plate making. Kraft fiber texture can soften highlights - better to catch that on the proof than after the first print run.

Existing size, unprinted: 5,000 pcs, base price, 12–15 days
Existing size, gravure: 10,000 pcs, plate fee plus volume pricing, 15–20 days
Size change, gravure: 10,000 pcs, larger size costs more, 18–22 days
Digital: from 5,000 pcs, no plate fee, higher unit price, 10–12 days
Material change: 20,000 pcs, add 5–7 days
Window, hang hole or tear notch: 10,000 pcs, small surcharge, add 1–2 days
One-way valve: 20,000 pcs, add 3–5 days

Plate fee is one-time per artwork. Repeat orders with the same file don't pay it again. MOQ is per size, per artwork - mixed sizes don't combine. Lead time starts after artwork and pre-production sample sign-off, not counting shipping.

If you have a promotion date locked in, tell us that first. We'll work backward and say honestly whether the schedule is tight, before you pay for plates.



Quality Checks

When choosing manufacturers for Zip Lock Bags, make sure to include in the sample agreement a heat-sealing strength at necessary temperature, closure of zipper after a powder test, and space between the window edge and seal line. These three aspects provide more information than the name of the laminate material itself.



On our side: heat-seal is checked at the agreed temperature. If your bar has a different profile, send the drawing and we'll simulate it. Zipper reclose gets tested after repeated cycles, and for powder we also check whether powder sits in the track after a fill trial. Lamination strength is checked between layers. Batch color is checked against the approved sample under the same light - kraft tone drifts a little from batch to batch, so the sample stays with the QC file.



We keep raw material and machine records, retain samples 6 months, and can send COA plus food-contact documents on request. Production-caused seal failures, color issues or size deviations are handled by replacement or credit based on the actual defective count.

5
Sampling Flow

Artwork check

file verified, text outlined, CMYK or Pantone confirmed. Window safe zone and zipper landing area marked on the proof.

01

White bag sample

3–5 working days. See our free sample policy. A photo of your filler nozzle helps us check the opening fit first.

02

Printed sample

7–10 working days. Kraft texture reviewed under daylight and shop light.

03

Pre-production sample

sealing, zipper and window validated. If you can run a small fill trial and send the sealed bag back, we'll cut it open and check the seal profile.

04

Production

scheduled after sign-off.

05

6


About Kazuo Beyin

Kazuo Beyin Paper and Plastic Packing Co., Ltd runs gravure printing, lamination and bag-making in one factory, so size changes, zipper selection and window position go through one technical contact instead of three departments. See our company profile and equipment list.

  • Clean workshop, pest control, foreign matter management. Inline CCD flags seal offset, zipper misalignment and window deviation.
  • COA and food-contact statements for substrate, ink and adhesive.
  • Long export history; familiar with destination labeling rules.
  • 9-color gravure press, dry and solventless lamination, stand-up zipper bag machine with CCD, independent curing room. 10-color artwork depends on press assignment.
  • Four checks before delivery: heat-seal, zipper reclose, drop test, seal integrity.
  • Curing runs by the process sheet. We don't shorten it to save a day - under-cured laminate can feel fine on the roll and still fail at the seal.
FAQ

Q: Frozen storage?

A: Not with the standard structure. It's built for dry, ambient products. Frozen needs a different PE grade and a low-temperature seal trial.

Q: Fine powder in the zipper?

A: Yes, if the fill area isn't cleaned. Leave a clear strip above the fill line. Send a photo of the filled opening and we'll mark where powder tends to collect.

Q: Is it recyclable or is it mono-material?

A: Multi-layer material is the point of reference but the recyclability depends on local collection specifics. We can consider using mono-PE/PP or paper-based alternatives, however, performance testing of barrier and zipper is required.

Q: Lot codes or QR codes?

A: Gravure is fixed artwork. Variable data usually goes on with inkjet or labels. If the code sits near the zipper or window, send the layout and we'll check the clear area.

Q: Packing for shipment?

A: Carton count, orientation and pallet plan depend on size, thickness and transport. Confirmed after the pre-production sample. Stand-up bags are usually kept flat, and we don't over-compress the bottom gusset.

Q: Payment terms?

A: Confirmed in the proforma invoice before production. First orders are handled case by case.



What to Send Us



  1. Bag size - width × height + gusset
  2. Structure or barrier requirement
  3. Thickness
  4. Print colors and artwork file
  5. Quantity
  6. Product type and fill weight
  7. Filler model and sealing temp, if you have them
  8. Destination country



If you're sourcing Zip Lock Bags for a powder line, fill weight and sealing temperature are the two that matter most. That's enough to recommend film, thickness and zipper model before you pay for plates. A photo of the nozzle or sealing bar usually saves a round of emails. Comparing formats? See related stand-up pouches.
